How To Fit Studs
Your are here: Home » Free Trial » Free Trial: BHS Stage Three » Stage 3: Care A » 3. Fitting Studs » How To Fit Studs‹‹ Go back

Studs must not be fitted to a worn or thin shoe. This is because the stud may protrude past the end of the shoe and press into the sole of the hoof.

Step 1

Pick up the horse’s hoof.

Using a horseshoe nail (or something similar) remove the cotton wool or stud plug from the hole. Ensure the hole is free from debris.

Spraying a small amount of WD40 into the hole will help to clean it thoroughly.


Step 2

Using the stud tap, screw it into the hole to re-thread it.

When the studs are not fitted, the outside edge of the hole can become spoilt due to normal wear and tear of the shoe. Re-threading will correct this issue and allow the stud to be fitted easily.


Step 3

With your fingers very carefully screw the stud into the hole, avoiding cross threading.


Step 4

Once the stud is fitted at hand tightness, use the spanner to secure it. Do not over-tighten.


A Fitted Stud
